1、基础参数
♦ Display Mode: Passive Matrix
♦ Display Color: Monochrome (White)
♦ Drive Duty: 1/48 Duty
♦ Number of Pixels: 64 x 48
♦ Panel Size: 18.46 x 18.1 x 1.25 (mm)
♦ Active Area: 13.42 x 10.06 (mm)
♦ Pixel Pitch: 0.21 x 0.21(mm)
♦ Pixel Size: 0.19 x 0.19 (mm)
♦ Driver IC: SSD1306
♦ Interface: 8-bit 68XX/80XX Parallel, 4-wire SPI, I2C
2、绝对最大值&光学特性
3、工程图纸
焊接款
接插款
|
