1、基础参数
♦ Display Mode: Passive Matrix
♦ Display Color: Monochrome (White)
♦ Drive Duty: 1/32 Duty
♦ Number of Pixels: 128 × 32
♦ Panel Size: 30.0 × 11.5 × 1.23 (mm)
♦ Active Area: 22.384 × 5.584 (mm)
♦ Pixel Pitch: 0.175 × 0.175 (mm)
♦ Pixel Size: 0.159 × 0.159 (mm)
♦ Weight: 1.05g
♦ Driver IC: SSD1306
♦ Interface: IIC
2、绝对最大值&光学特性
3、工程图纸
|
