1、基础参数
♦ Display Mode: Passive Matrix
♦ Display Color: 65,536 Colors (Maximum)
♦ Drive Duty: 1/64 Duty
♦ Number of Pixels: 96 (RGB) × 64
♦ Panel Size: 25.70 × 22.20 × 1.50 (mm)
♦ Active Area: 20.14 × 13.42 (mm)
♦ Pixel Pitch: 0.07 × 0.21 (mm)
♦ Pixel Size: 0.05 × 0.19 (mm)
♦ Weight: 1.8 (g)
♦ Driver IC: SSD1331Z
♦ Interface: 8-bit 68XX/80XX Parallel, 4-wire SPI
2、绝对最大值&光学特性
3、工程图纸
|
